Clarity Vision Pro - Professional SMD Outdoor LED Series

Premium Performance. Built for Touring. The Clarity Vision Pro Series is engineered for the demands of the outdoor rental and events market. It combines stunning high-brightness visual quality with a patented, quick-lock modular cabinet design that allows for extremely fast setup, teardown, and configuration into massive, seamless video walls.

Clarity Vision Pro Outdoor Rental LED
Tool-Free, Single-Person Fast Locking System
Up to 7,000 nits High Brightness
IP65 Rated for Outdoor Events
Lightweight Profile Aluminum Die-Cast Cabinet
Front/Rear Module and Power Maintenance
Multiple Cabinet Sizes (500×1000mm & 1000×1000mm)

Product Overview

Key Highlights

Energy-Efficient Common Cathode

Advanced circuit design ensures lower heat generation and reduced power usage.

Optimal Pixel Pitch Options

Available in P2.97, P3.91, P4.81, P6.25, P7.81, and P10.42 for long-distance viewing.

Ultra High Contrast Ratio

Delivers deeper blacks and crisp visuals with ≥15000:1 contrast performance.

Lightweight 25kg Cabinet

Easy to handle and ideal for quick event setups and large modular video walls.

Dual Service Access

Modules and power components can be serviced from both the front and rear.

Full IP66 Protection

Completely waterproof and dustproof for all-weather outdoor operation.

Standard Cabinet Size

1000 × 1000 × 78 mm frame ensures compatibility across event configurations.

Ultra High Refresh Rate

≥3840Hz ensures flicker-free performance for live concerts and broadcasts.

Ultra High Brightness

Achieves ≥6500 nits for daytime outdoor visibility during events.

Technical Specifications

Technical Parameters P2.97 P3.91 P4.81 P6.25 P7.81 P10.42
Pixel Composition (SMD) 1415 1415 1921 2727 1415 1415
Pixel Pitch (mm) 2.97 3.91 4.81 2.604 2.97 3.91
Module Resolution (W×H) 168×84 128×64 104×52 80×40 64×32 48×24
Module Size (mm) 500×250×16 500×250×16 500×250×16 500×250×16 500×250×16 500×250×16
Module Weight (kg) 1.93 1.93 1.93 1.93 1.93 1.93
Module Qty / Cabinet (W×H) 2×4 2×4 2×4 2×4 2×4 2×4
Cabinet Resolution (W×H) 336×336 256×256 208×208 160×160 128×128 96×96
Cabinet Size (mm) 1000×1000×78 1000×1000×78 1000×1000×78 1000×1000×78 1000×1000×78 1000×1000×78
Cabinet Area (㎡) 1.0 1.0 1.0 1.0 1.0 1.0
Cabinet Weight (kg/cabinet) 25 25 25 25 25 25
Cabinet Material Aluminium Profiles Aluminium Profiles Aluminium Profiles Aluminium Profiles Aluminium Profiles Aluminium Profiles
Cabinet Density (dot/m²) 1,12,896 65,536 43,264 25,600 16,384 9,216
IP Rating IP66 IP66 IP66 IP66 IP66 IP66
White Balance Brightness (nits) ≥5000 ≥5500 ≥5500 ≥5500 ≥5500 ≥5500
Color Processor (bit) 16 16 16 16 16 16
Color Temperature (K) 6500–9000 6500–9000 6500–9000 6500–9000 6500–9000 6500–9000
Visual Angle (H/V) 140° / 120° 140° / 120° 140° / 120° 140° / 120° 140° / 120° 140° / 120°
Luminous Point Centre Deviation <3% <3% <3% <3% <3% <3%
Luminance Uniformity ≥97% ≥97% ≥97% ≥97% ≥97% ≥97%
Chromaticity Uniformity Within ±0.003Cx, Cy Within ±0.003Cx, Cy Within ±0.003Cx, Cy Within ±0.003Cx, Cy Within ±0.003Cx, Cy Within ±0.003Cx, Cy
Contrast Ratio ≥8000:1 ≥8000:1 ≥8000:1 ≥8000:1 ≥8000:1 ≥8000:1
The Max Power Consumption (W/㎡) 550 550 550 550 550 550
Average Power Consumption (W/㎡) 186 186 186 186 186 186
Input Voltage AC100~240V AC100~240V AC100~240V AC100~240V AC100~240V AC100~240V
Frequency (Hz) 50&60 50&60 50&60 50&60 50&60 50&60
IC Driving 1–21 1–8 1–7 1–5 1–4 1–2
Refreshing Ratio (Hz) 3840 3840 3840 3840 3840 3840
Maintenance Method Front and Rear Front and Rear Front and Rear Front and Rear Front and Rear Front and Rear
Lifespan (hrs) 1,00,000 1,00,000 1,00,000 1,00,000 1,00,000 1,00,000
Work Temperature / Humidity -40℃–80℃ / 10%RH–98%RH (Non Condensing) -40℃–80℃ / 10%RH–98%RH (Non Condensing) -40℃–80℃ / 10%RH–98%RH (Non Condensing) -40℃–80℃ / 10%RH–98%RH (Non Condensing) -40℃–80℃ / 10%RH–98%RH (Non Condensing) -40℃–80℃ / 10%RH–98%RH (Non Condensing)
Storage Temperature / Humidity -20℃–60℃ / 10%RH–98%RH (Non Condensing) -20℃–60℃ / 10%RH–98%RH (Non Condensing) -20℃–60℃ / 10%RH–98%RH (Non Condensing) -20℃–60℃ / 10%RH–98%RH (Non Condensing) -20℃–60℃ / 10%RH–98%RH (Non Condensing) -20℃–60℃ / 10%RH–98%RH (Non Condensing)
Certification CE, FCC, ROHS, EMC, LVD, BIS
