ClarityWall – DOOH & Outdoor Billboards LED Series

Outdoor High-Brightness LED Display

ClarityWall – DOOH & Outdoor Billboards LED Series

Extreme Visibility. All-Weather Durability. The ClarityWall Series is engineered for maximum impact in Digital Out-of-Home (DOOH) advertising, featuring ultra-high brightness (up to 8,500 nits) and a robust, fully sealed, weatherproof design for reliable 24/7 operation.

ClarityWall Outdoor Billboard LED
Ultra-High 8,500 nits Brightness
IP65/IP66 Fully Weatherproof Rating
Energy-Saving Common Cathode Technology
Slim & Lightweight Aluminum Cabinet
Wide Operating Temperature Range
Quick Lock System for Fast Installation

Product Features

Key Highlights

Energy Efficient Design

Common Cathode Circuit Technology reduces power consumption significantly.

Optimal Pixel Pitch Options

Available in P4.4, P5.7, P6.67, P8, and P10 for long-distance outdoor visibility.

Ultra High Contrast Ratio

Produces deep blacks and vivid colours with ≥15000:1 contrast.

Lightweight Cabinet

26.5 kg die-cast aluminium body enabling easy transport and installation.

Front & Rear Maintenance

Convenient dual-access design supports fast servicing in any installation scenario.

IP66 Weatherproof Protection

Fully sealed cabinet for complete waterproof and dustproof performance.

Extreme Brightness

Up to 8,500 nits ensures clear visibility even under direct sunlight.

Standard Cabinet Size

Uniform 960×960 mm cabinet layout ensures easy scalability and modular installation.

Ultra High Refresh Rate

Maintains smooth, flicker-free playback with ≥3840Hz refresh rate.

Technical Specifications

Technical Parameters P4.44 P5.7 P6.67 P8 P10
Pixel Composition (SMD) 1415 2727 2727 2727 2727
Pixel Pitch (mm) 4.44 5.7 6.67 8 10
Module Resolution (W×H) 108×72 84×56 72×48 60×40 48×32
Module Size (mm) 480×320×14 480×320×15 480×320×16 480×320×17 480×320×17
Module Weight (kg) 2 2 2 2 2
Module Qty / Cabinet (W×H) 2×3 2×3 2×3 2×3 2×3
Cabinet Resolution (W×H) 216×216 168×168 144×144 120×120 96×96
Cabinet Size (mm) 960×960×85 960×960×86 960×960×87 960×960×88 960×960×88
Cabinet Area (㎡) 0.92 0.92 0.92 0.92 0.92
Cabinet Weight (kg/cabinet) 26.5 25 25 25 25
Cabinet Material Die-cast Aluminium Die-cast Aluminium Die-cast Aluminium Die-cast Aluminium Die-cast Aluminium
Cabinet Density (dot/m²) 50625 30625 2250 15625 10000
IP Rating IP66 IP66 IP66 IP66 IP66
Circuit Design Common Cathode Technology Common Cathode Technology Common Cathode Technology Common Cathode Technology Common Cathode Technology
White Balance Brightness (nits) 5000 7000 6500 7000 7000
Color Processor (bit) 16 16 16 16 16
Color Temperature (K) 6500-9000 6500-9000 6500-9000 6500-9000 6500-9000
Visual Angle (H/V) 160°/160° 160°/160° 160°/160° 140°/120° 140°/120°
Luminous point centre deviation <3% <3% <3% <3% <3%
Luminance uniformity ≥97% ≥97% ≥97% ≥97% ≥97%
Chromaticity uniformity Within ±0.003Cx, Cy Within ±0.003Cx, Cy Within ±0.003Cx, Cy Within ±0.003Cx, Cy Within ±0.003Cx, Cy
Contrast Ratio ≥15000:1 ≥15000:1 ≥15000:1 ≥15000:1 ≥15000:1
The Max Power Consumption (W/㎡) 600 550 550 550 550
Average Power Consumption (W/㎡) 200 186 186 186 186
Input Voltage AC100~240V AC100~240V AC100~240V AC100~240V AC100~240V
Frequency (Hz) 50&60 50&60 50&60 50&60 50&60
IC Driving (Scan) 1-9 1-7 1-6 1-3 1-2
Refreshing Ratio (Hz) 3840 3840 3840 3840 3840
Maintenance Method Front and Rear Front and Rear Front and Rear Front and Rear Front and Rear
Lifespan (hrs) 100,000 100,000 100,000 100,000 100,000
Work Temperature / Humidity -40℃~80℃ / 10%RH-98%RH (Non Condensing) -40℃~80℃ / 10%RH-98%RH (Non Condensing) -40℃~80℃ / 10%RH-98%RH (Non Condensing) -40℃~80℃ / 10%RH-98%RH (Non Condensing) -40℃~80℃ / 10%RH-98%RH (Non Condensing)
Storage Temperature / Humidity -20℃~60℃ / 10%RH-98%RH (Non Condensing) -20℃~60℃ / 10%RH-98%RH (Non Condensing) -20℃~60℃ / 10%RH-98%RH (Non Condensing) -20℃~60℃ / 10%RH-98%RH (Non Condensing) -20℃~60℃ / 10%RH-98%RH (Non Condensing)
Certification CE, FCC, ROHS, EMC, LVD, BIS
